GAZEEBO CYBORG PROTOTYPE FIRST MODULE

GAZEEBO CYBORG PROTOTYPE
FIRST MODULE - VIDEO CCD HEAD ASSEMBLY

By SpLiFFoRd and Lucid

CCD Body element h4x0r3d to computer power supply
BNC/RCA into switching box

Camera head mounted on tripod

After tweaking the head assembly...
The first clear image! We did it!

Lucid works on motor research

Setting the focus and picture

Looks like it works!

Lucid adjusts the new cam head and SpLiFFoRd, after 15 penguin caffeine mints
and 3 jugs of coffee, tweaks the image



Gazeebo Cyborg Cam head in action
